Tungsten carbide has a high strength level, especially for a material that is three times as rigid as steel, and 4-5 times as rigid as iron. It resists deformation well, has good impact resistance, and can handle extremely low and high temperatures easily. Tungsten carbide has a high strength level, especially for materials whose stiffness is three times that of steel and 4-5 times that of iron. It has good deformation resistance, good impact resistance, and can easily cope with extremely low and extremely high temperatures. These characteristics make tungsten carbide ball products a popular choice in the case of traditional steel failure. Therefore, our tungsten carbide ball bearings are suitable for any combination of high temperature and stress.
| Tungsten Carbide Balls | ||||||||||
| 1. Material | YG6/ YG8/ YN6/ YN13/ YG6X | |||||||||
| 2. Size Range | 0.5mm-80mm | |||||||||
| 3. Grade | G10-200 | |||||||||
| 4. Composition | WC94%, CO6% | |||||||||
| 5. Characteristic | (a)Very high hardness (b)Good abrasion resistance (c)High vibration resistance | |||||||||
| 6. Magnetic | Nearly Non-magnetic | |||||||||
| 7. Application | Valve, precious bearing, grinding, Golf counterweight, Fishing pendant, mobile phone vibration. | |||||||||
| 8.Packing | Standard: 10kg or 20kg per carton, 1 ton per pallet or as customer required | |||||||||
| 9.Conditioning | Dry / Oil | |||||||||
| 10.Delivery time | Stock within a short time or 35 days. | |||||||||
| Grade: G10 to G1000 | |||||
| Grade | ball diameter | spherical | surface | lot diameter | nomainal ball |
| variation | deviation | roughness | variation | deviation tolerance | |
| Vdws | Sph | Ra | Vdwl | Tdn | |
| not over | |||||
| μm | |||||
| 10 | 0.25 | 0.25 | 0.02 | 0.5 | * |
| 16 | 0.4 | 0.4 | 0.025 | 0.8 | * |
| 20 | 0.5 | 0.5 | 0.032 | 1 | * |
| 24 | 0.6 | 0.6 | 0.04 | 1.2 | * |
| 28 | 0.7 | 0.7 | 0.05 | 1.4 | * |
| 40 | 1 | 1 | 0.06 | 2 | * |
| 60 | 1.5 | 1.5 | 0.08 | 3 | * |
| 100 | 2.5 | 2.5 | 0.1 | 5 | ±12.5 |
| 200 | 5 | 5 | 0.15 | 10 | ±25 |
| 500 | 12.5 | 12.5 | * | 25 | ±50 |
| 1000 | 25 | 25 | * | 50 | ±125 |
| Standard Packing | |||
 | |||
| More packing methods, please contact us. |
